Download the Caterpillar 323 GX Excavator KTB Electrical & Hydraulic Schematic Manual in PDF. Complete wiring diagrams and hydraulic schematics for accurate troubleshooting, service, and repair.
Availability: In Stock
This official Caterpillar Electrical and Hydraulic Schematic Manual is designed for the 323 GX Excavator with Serial Number prefix KTB. It provides complete, factory-verified diagrams covering all aspects of the electrical and hydraulic systems. The electrical schematics feature detailed wiring diagrams, harness connections, fuse/relay panels, sensors, switches, and control modules to ensure precise fault detection and efficient repair. The hydraulic section illustrates pumps, valves, cylinders, hose routing, and flow paths, enabling accurate servicing and troubleshooting. With clear labeling, structured layouts, and step-by-step diagrams, this manual is essential for technicians, engineers, and operators to maintain the reliability, safety, and peak performance of the 323 GX.
Includes ALL DIAGRAMS & PICTURES for 323 GX EXCAVATOR KTB
Format: PDF
Language: English
Download Instructions: PDF will be delivered to your email after purchase
